Guriga> Alaabta> Deynta iyo Daaweynta Qashinka> Mashiinka yareynta dhimista> Cadhada taxanaha ee culayska culus ee culus





 

Cadhada taxanaha ee culayska culus ee culus

Nooca Bixinta: L/C,T/T

Gaadiidka: Ocean,Land,Air,Express,Mixed way

$467650
1-2 Set/Sets
$446500
3-5 Set/Sets
$424500
≥6 Set/Sets

Model	CIT-20
Purification rate
option	900 M3 Per Hour
Kala xiriir Hada

Sifooyinka Badeecada Kartida Bixinta & Macluumaad Dheeraad ah

Sifooyinka Badeecada

Tusaale ahaan.: CIT-20

Brand: Ubax

Origin: Maacuun

Shahaadada: Iso 9001:2015

Darajo: Cusub

Warshadaha Lagu Dabaqi Karo: Tamarta & Macdanta, Warshada Cuntada & Cabitaanka, Warshad Warshad, Dukaamada Cuntada & Cabitaanka, Beeraha

Adeegga Diyaarinta: Video taageero farsamo, Taageerada khadka tooska ah, Qaybaha dayactirka, Dayactirka iyo dayactirka goobta

Kormeerka Warshadaha Fiidiyowga: Bixiyay

Warbixinta Imtixaanka Makaanikada: Bixiyay

Nooca Suuqgeynta: Alaab Cusub 2020

Muddada Caymiska Qaybta Core: 2 sano

Qaybaha Aasaasiga Ah: Gearbox, Mashiinka, Dhalista, Gawaarida, PLC

Meesha Asalka Ah: Shiinaha

Waqtiga Damaanada: 1 Sannadood

Heer Wax Soo Saar: 500L / Saacad, 10000L / Saacad, 20000L / Saacad, 2000L / Saacad, 3000L / Saacad, 5000L / Saacad, 4000L / Saacad, 7500L / Saacadda, 50000L / Saacad, 2500L / Saacad

Key Function: Heavy Sludge or Slurry Thickener

Key Parts: Hydraulic station and Inclined Tube

Scraper: Auto Rake Lifting Way

Slurry: Tube abSorption

Run Speed Modifing: Stepless Speed Regulation

Deep Tangential Feeding: From bottom to upper

Advection Settling: In Good Function

Dilution: Automatically

Lubricated System: Reliable

Maintenance: Easily

Tafaasiisha Sheyga

CIT taxanaha tuubbada tuubada tuubada tuubada tuubada ayaa ku kacaya kor u qaadida slurry jilicsan

Qulqulka barkadda barkadaha ee auto

Waa cufnaanta cusub ee cufnaanta ka dib markii uu nuugo tikniyoolajiyadda sare ee dibedda oo ay ku jirto biyo-gawaarida wadista baabuurta iyo xoojinta xawaaraha xawaaraha.

Macdanta Maskaxda Maskaxda Auto auto otomed qaab dhismeedka muuqaalka iyo faa'iido

- Waxay qaadataa wadis-biyood oo ay ku wado taageerada saqafka si loo badbaadiyo nus xoog

Waqtigiisa nolosha sii ballaarata

- Hayso dheelitirka galka ah iyo isku-darka si isku mid ah

- Xeerka xawaaraha xawaaraha ee xajikanka wuxuu xaqiijinayaa cufnaanta qulqulka qulqulka iyo qulqulka qulqulka

Biyo la jaan qaada xaalad codsade oo kala duwan

- Gawaarida gawaarida si loo hubiyo in la hubiyo in nidaamku deggan yahay

- Quudin aad u qoto dheer oo ka socota hoose ilaa sare

- Ku faallo dejinta

- dilid otomatic ah

- Nidaam la isku halleyn karo oo la isku halleyn karo oo leh howsha dayactirka fudud

- Baarkin deg deg ah, oo soo dejiso & fuulitaan

- Naqshad macquul ah oo ah tuubada quudinta ee hoos timaada goynta centrifult dejinta

- Qaado xawaare aad u sareeya oo leh sinta sare, sagxadda dabaqa weyn

- Taageerada farxadda leh ee birta ah waxay yareysaa isticmaalka awoodda, iska caabbinta biyaha si kor loogu qaado xooggeeda oo ay kordhiso awoodda flotation.

XARUNTA MACLUUMAADKA XAALADAHA EE DUGSIGA SIYAASADDA SIYAASADDA CIYAARADA

Waxay ka kooban tahay aaladda waditaanka, buundada, tuubbada qasabka , qafis, raashin, weel dhar, saldhig biyo-saar, sanaadiiqda kontoroolka korantada iyo qaybaha kale.

Foomka xulashada iyo xudunta loogu talagalay cit taxanaha gawaarida gawaarida gawaarida kor u qaadida xarunta qaabeynta wadista

Model	Height mm	Settler Area m²	Rake Shaft Speed RPM	Rake Speed mm/min	Rake Lift Height mm	Capacity M3/h	Motor Power kw	Weight kg
CIT-6	3100	28.27	2.5~5	150	350	60~80	3	5297
CIT-8	4782	50	3~5	150	500	100~200	7.5	18310
CIT-9	2918	63.6	2~10	150	400	125~190	4	12576
CIT-12	5990	113	2~10	150	400	280~340	4	16643
CIT-15	4794	176	5~15	150	400	440~530	5.5	18792
CIT-16	4396	201	5~15	150	450	500~600	5.5	19826
CIT-18	5050	254	5~20	150	450	635~760	5.5	21638
CIT-20	5144	314	5~20	150	500	785~940	7.5	26977
CIT-21	5241	346	5~20	150	450	865~1040	7.5	28096
CIT-22	6776	380	5~20	150	450	950~1140	7.5	29134
CIT-24	6250	452	5~20	150	450	1130~1357	7.5	31998
CIT-30	5915	706	10~20	150	450	1765~3120	7.5	39775
CIT-35	6955	962	10~20	150	600	2405~2885	14	47950
CIT-38	6323	1134	10~20	150	600	2835~3400	14	51073
CIT-20	7220	314	5~20	150	500	~1500	11	36299
CIT-24	7664	452	10~20	150	500	~2100	11	55673
CIT-30	8325	706	10~20	150	500	~1500	18.5	68581
CIT-38	8711	1134	10~20	150	800	1800-2500	11	58528
CIT-45	8033	1590	15~22	150	800	2400-3000	11	77200
CIT-53	6946	2206	15~22	150	600	3000-4000	15	99610
CIT-65	8439	3012	16~23	150	600	4500-8000	18.5	130100
CIT-80	9385	5026	20~60	150	600	8000-11000	22	192040
CIT-100	8832	7852	20~60	150	800	15000-18000	30	239850

Hydraulic drive tuubada dhumucda

-Maalinta daaweynta culus ee slurry culus

-Qaar daaweyn culus oo culus

-Qaar ka baaraandegista qarka u adag

-Maalinta ka shaqeynta daaweynta qaro weyn

-Didajiyaha wasakhda wasakhda qashinka

-Ku dabaqa barkadaha barkadaha culus

Baakado & Gaarsiin

Iibinta Cutubyada	:	Set/Sets
Nooca Xirmada	:	Sanduuq alwaax ah ama alwaax alwaax ah
Sawir Tusaale	:

The file is encrypted. Please fill in the following information to continue accessing it

Inquire the password

Kartida Bixinta & Macluumaad Dheeraad ah

Baakadaha: Sanduuq alwaax ah ama alwaax alwaax ah

Wax-soo-saarka: 30 Sets Per Three Months

Gaadiidka: Ocean,Land,Air,Express,Mixed way

Goobta Asalka: Maacuun

Kartida Bixinta: 30 Sets Per Three Months

Shahaadada: Iso 9001:2015

HS Code: 8421219990

Port: Shanghai,Ningbo,Qingdao

Nooca Bixinta: L/C,T/T

Madadaalo: FOB,CFR,CIF,EXW,FAS,FCA,CPT,CIP,DEQ,DDP,DDU,Express Delivery,DAF,DES
